General

Supports LGA1155 Socket 13/15/17 series CPU

Intel H61 Express Chipset

2*240-pin DDR3 SDRAM Slots, Memory up to 16GB, Supports
dual channel DDR3 1066/1333/1600MHz

6 x USB 2.0, 1 x VGA port, 1 x HDMI port, 1 x RJ45 port, 1 x 3-in1 Audio Port (line In / Line Out / MIC IN)

1 x 24-pin ATX power connector, 1 x 4-pin ATX 12V power connector, 2 x USB connector, can support 4*USB 2.0,
1 x F_AUDIO connector, 1 x F_PANEL connector
1 x SPEAKER connector, 2 x FAN connector

With 6-channel HD Audio Codec onboard provides front audio
interface; provides front stereo mic interface

3 x SATA2.0 (3GB/s) ports

With 10/100 Mbps LAN onboard

1 x PCI Express x16 slot, 1 x NVME/NGFF slot

Micro-ATX architecture (17*17 cm)
